MIL-PRF-62315 Heater Assembly, Combustion Vehicular Compartment, 60,000 Btu/Hr \(Use Mil-Prf-62550\)This specification establishes the performance, design, testing, manufacturing, and acceptance requirements for a forced air inlet personnel heater assembly, referred to herein as "heater" \(see 6.1\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11

MIL-PRF-62315C

Part Identifying Number (PIN)

Prior MS part number

M62315-D

MS52288

NOTES:

1. Combustion air inlet must be rotatable to any angle within the 290� range and

securable in any angle such that shock or vibration shall not result in a change

of position.

2. A minimum installation clearance of 4 inches at the air inlet to the blower must be

provided. A minimum clearance of 3 inches above the heater cover is required for

servicing.

3. Dimensions are in inches. Unless noted, tolerances are: angular +1�,

2 place decimal +0.06 inches.

FIGURE 1. Heater assembly, combustion dual air type.
