A-A-52163 Ladders, Vehicle-BoardingThis CID covers nine different types of portable, metal, step-ladders hereinafter referred to as ladders for use by personnel in boarding vehicles.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26

PIN number Number of steps Width, inside rails Width, outside rails Hook centers

Step depth First step rise Typical step rise Vertical step rise Angle with ground Material

W1

W2

H D R1

R2

R3

A

A52163-E1

5

457 mm (18 in)

527 mm (20.8 in)

492 mm (19.4 in)

178 mm (7 in)

240 mm (9.54 in)

254 mm (10 in)

1256 mm (49.4 in)

53°

Aluminum

A52163-E2

5

400 mm (15.8 in)

470 mm (18.5 in)

435 mm (17.1 in)

178 mm (7 in)

240 mm (9.45 in)

254 mm (10 in)

1256 mm (49.4 in)

53°

Aluminum
